Here’s the step-by-step process to program an Arduino board with a Mac: Downloading and installing Arduino on a Mac. Step 1: Get all the needed equipment in place. This means having with you the Arduino Uno board and the USB data cable that will help you connect the board to your Mac.

1. Install Arduino On Mac Laptop
2. Install Arduino On Mac Keyboard
3. Install Arduino On Mac Computers
4. Install Arduino On Mac Download

Install Arduino On Mac Laptop

It took me way too long to get started with the WeMos D1 R2 board, partly because mine is an eBay knockoff.

1. Welcome to Learn ESP32 with Arduino IDE: Unit 2: Introducing ESP32: Unit 3: Installing the ESP32 Board in Arduino IDE (Windows, Mac OS X, and Linux) Unit 4: How To Use Your ESP32 Board with this Course: Unit 5: Make the ESP32 Breadboard Friendly: Unit 6: ESP32 Troubleshooting Guide: Unit 7 Optional Programming ESP32 with Atom Text Editor.
2. Mac OS X: When you run Arduino after installing Teensyduino, the Leopard's firewall will recognize the program has changed and will ask again if you wish to allow internet connection (Arduino checks for updates). Teensyduino does not 'phone home', but Arduino does!
3. Go to the Arduino download page and download the latest version of the Arduino software for Mac. When the download is finished, un-zip it and open up the Arduino folder to confirm that yes, there are indeed some files and sub-folders inside.
4. Restart the Arduino IDE; Try a different micro USB cable; In Finder, navigate to /Library (to get to Library, click on Go, then press control, and click on Library). Rename Arduino15 to Arduino15-backup.Download and install the latest version of the Arduino IDE (replace your current version)Open Arduino, re-install esp8266 in the Boards Manager.

1. Download and install the Arduino IDE (just called Arduino): https://www.arduino.cc/en/Main/Software Note: I use version 1.6.8, newer versions may not work.
2. Open Arduino
3. Open File → Preferences
4. Copy and paste http://arduino.esp8266.com/stable/packageesp8266comindex.json into Additional Boards Manager URLs field. You can add multiple URLs, separating them with commas
5. Open Tools → Board:xxx → Boards Manager and install esp8266 by ESP8266 Community

1. Open Tools → Board:xxx and select WeMos D1 R2 & mini.
2. Open Tools → Upload Speed and select 115200. If you're brave, you can try 230400 to upload code to the board faster, but watch the console for errors.
3. Download a driver so your Mac recognizes the WeMos D1 board (the site looks sketchy, but I can confirm the driver is legit): Note: This driver is needed for both real and knockoff D1 boards. http://www.wch.cn/download/CH341SERMACZIP.html

1. Plug your WeMos D1 board into your Mac using a micro USB.
2. Open Tools → Port:xxx and in the dropdown, select the option with 'usb' in its name.
3. Your Tools dropdown should look like this:

1. To make sure everything is working properly, let's download WeMos' example files: https://github.com/wemos/D1miniExamples/archive/master.zip
2. Rename the uncompressed directory to D1miniExamples
3. In Arduino, open File → Preferences
4. In Finder, navigate to the Sketchbook location show in in Arduino's Preferences
5. Move the D1miniExamples directory to Sketchbook location
6. The path will look like Sketchbookdirectory/D1mini_Examples
7. Restart the Arduino IDE
8. All examples are under File→Sketchbook→D1miniExamples

1. Open File→Sketchbook→D1miniExamples→01.Basics→HelloWorld
2. Click Upload
3. After upload, open Tools→Serial Monitor, set baudrate to 9600 baud

If you've gotten to this point, good work! Now we're going to learn a bit more about the WeMos D1's I/O ports. They're f***ed.

The fact that I have a knockoff board doesn't help either. Anyways, enough complaining. Basically, the labels on the WeMos D1 are not the same as those used in Arduino programs.

As an example, if I want to use digital port 3 (D3) as an output, this is the code I would use:

I've created a couple of reference tables for your convenience.

Official WeMos D1 Board Label	Knockoff WeMos D1 Board Label	Digital Port	Arduino Software
RX	RX<-D0	D0	3
TX	TX->D0	D1	1
D0	D2	D2	16
SCL/D1	D15/SCL/D3	D3	5
SDA/D2	D14/SDA/D4	D4	4
D3	D13/SCK/D5	D5	0
D4	D12/MISO/D6	D6	2
D5	D11/MOSI/D7	D7	14
D6	D8	D8	12
D7	TX1/D9	D9	13
SS/D8	D10/SS	D10	14
MOSI/D7	D11/MOSI	D11	13
MISO/D6	D12/MISO	D12	12
SCK/D5	D13/SCK	D13	14
SDA/D2	D14/SDA	D14	4
SCL/D1	D15/SCL	D15	5

Note: I can't guarantee the official WeMos D1 board mappings are correct, but they're based off this:
http://www.instructables.com/id/Programming-the-WeMos-Using-Arduino-SoftwareIDE/?ALLSTEPS

1. Restart the Arduino IDE
2. Try a different micro USB cable
3. In Finder, navigate to ~/Library (to get to Library, click on Go, then press control, and click on Library). Rename Arduino15 to Arduino15-backup.Download and install the latest version of the Arduino IDE (replace your current version)Open Arduino, re-install esp8266 in the Boards Manager.

If you have any other troubleshooting tips, send them my way.

A good amount of the content here is based on the official WeMos documentation ( http://www.wemos.cc/tutorial/getstartedin_arduino.html ). I've simply filled in many of the gaps preventing my board from functioning properly.

This is what an actual WeMos D1 board looks like:

This is what my knockoff WeMos D1 board looks like:

Now you know how to set up your WeMos D1 board and use its ports. I'm going to leave out discussion on its WIFI capabilities because there's plenty of documentation on that already.

In the next article, I will discuss how to connect a stepper motor to the WeMos D1.

Jan 22, 2019 By Team YoungWonks *

How do you program an Arduino using a Mac? This blog will tell how. But before we get into that, let’s take a look at what is an Arduino?

What is Arduino?

An Arduino is basically a single board microcontroller that is used for building digital devices and interactive objects that can sense and control objects in the physical and digital world. These Arduino boards are available both in preassembled form or as do-it-yourself (DIY) kits. Arduino board designs use a variety of microprocessors and controllers. The boards come fitted with sets of digital and analog input/output (I/O) pins that can be interfaced to several expansion boards or breadboards (shields) and other circuits.

One of the biggest advantages that Arduino boards have over Raspberry Pi is the fact that they can read sensitive values from sensors and Arduino boards have analog input and output and not digital input output which is the case with Raspberry Pi. This is why in some instances - especially where exact values are needed - it is a more apt choice. Say, if you want to make a device that automatically waters your plants. Now to do this, you have to measure the exact soil moisture, so an Arduino is a better bet because it can read analog values as opposed to the Raspberry Pi which will need another chip to read analog values.

Arduino has low maintenance and doesn’t get disrupted by power outages. But image processing needs can be done better with Raspberry Pi and Pi camera.

In this blog, we shall look at how we can program an Arduino board using a Mac OS. Here’s the step-by-step process to program an Arduino board with a Mac:

Downloading and installing Arduino on a Mac

Step 1: Get all the needed equipment in place. This means having with you the Arduino Uno board and the USB data cable that will help you connect the board to your Mac.

You’ll also need a breadboard, jumper cables(M-M), an LED and a resistor (with a resistance of say, 330 Ohms).

Step 2: Then start by connecting the narrow end of the USB data cable to your Arduino board as shown below.

Step 3: Then connect the other end of the USB data cable to your Mac. At this stage, your Mac and the Arduino board have been connected to each other using the USB cable. Refer to the pic below.

Step 4: Now go on to download the Arduino IDE on your Mac. To do this, open Safari on your Mac and just go to the website www.arduino.cc. Once you have opened the website, go to the software section and click on downloads from the dropdown menu. Now select the Mac OS X version, hit download and wait for the download to finish. Once it downloads, one can run the Installer in the next step.

Step 5: To install the IDE, we need to run the file that we just downloaded. Click on Agree and continue with the default settings for the rest of the installation. Once the installation is done, click on the close button to finish the installation.

Now that we have downloaded and installed the Arduino IDE on our Mac, we can carry out a number of tasks using the Arduino IDE. This includes getting the board to say, “Hello World”, running the counter program and lighting an LED - all using the Arduino.

Saying “Hello World”

Let’s look at what goes into writing our first program, the “Hello World” program. Let’s open the Arduino IDE that we have installed on the Mac. Make sure you check the board name under the Tools option as Arduino Uno. Also make sure that the communication port is selected as COM3. Now to see the information sent by our Arduino, we have to open the serial monitor we see on the right.

In the program, we start by putting Serial.begin 9600 in the void setup function which is the one-time setup required for exchanging information over the serial port from the Arduino to the computer. 9600 here is called the baud rate. It is the rate at which the Arduino can send symbols or characters to the computer.

In the void loop function, we use a very simple serial.print to show data on the serial monitor.

You can first save it and then upload the design onto the Arduino. You’ll then see that the words “Hello World!” are being sent by the Arduino to the computer and we can see the words on the serial monitor. You’ll see that the words “Hello” and “World” are appearing next to each other. However, if we use a n in our print command, we will see the two words printed one below the other.

Running the Counter Program

Let’s take a look at the next program. We will design a simple counter by opening the Arduino IDE and the serial monitor. Let’s start by defining the counter variable. Here we say int <space> counter equals one and add a semicolon at the end. This initializes the value of the counter to 1 at the beginning. Now just like in the previous program, we initialize the serial connection.

In the loop, we print the counter value and we also increase the value of the count by one. Here, we use the printIn function to automatically add a new line after having printed the value of the counter. Now this would be too fast and for us to understand what’s happening in the output, we add a delay and the argument is in milliseconds. So for a one second delay, we provide an argument of thousand to the delay function. Finally, increase the value of counter by one using the counter++ statement. Once we save and upload this design onto the Arduino, we will be able to see that a counter variable is constantly being increased in value and this value is being communicated to the computer over the serial connection.

Lighting an LED

Lighting the inbuilt LED on the Arduino

Now the next program we will be working on is blinking the Arduino’s inbuilt LED. You can see that right next to pin number 13 among the digital pins, there’s an LED which is orange in colour. We will learn how to make it blink once every second. And just like we do with the Raspberry Pi, we will start by initializing the pin to be an output so we can control its values. Here we say pinMode and we say 13 which is the pin for the inbuilt LED and we set it as an output so that we can send values of high or low. We then begin our loop function by setting value of the 13 pin to 1 (or high). We do this by using the DigitalWrite function. We then add a delay of one second and then we set the value of the 13 pin as low. Don’t forget to add a delay after turning it low. Now when you run the code, you should be able to see the light next to the pin number 13 blink.

Writing the program to blink an LED on the breadboard

Here we will see how one can write the program that allows the Arduino to make an LED on the breadboard blink once every one second. Just like in the previous case, we will set values and this time, we will choose pin number 12 and we will set it as an output. So we type the pinMode, 12, output. In the void loop, we use the serial to communicate messages from the Arduino to the computer. We use the DigitalWrite function to turn the pin on or set it to high. Then we add the delay of one second. In the same fashion, we will turn the pin off by using the DigitalWrite function. Similarly, we can add a message and a delay so that we see the output very clearly.

Next you can save and upload this. Go to your Arduino, make sure you have the serial monitor open so you can see the output. Now this code seems to work as it prints LED high and LED low every one second. At this stage, we need to make an LED circuit on the breadboard and connect it to the Arduino to see the actual result.

Making connections to blink an LED on the breadboard

Now we will explore the connections to be made on the breadboard so as to make an LED blink from the Arduino.

Here’s how you make connections to blink an LED on the breadboard using an Arduino:

Just like with Raspberry Pi, we set up the LED first. We place the LED on the breadboard across the middle separation.

Then we add a resistor (say with a resistance in the range of 220 to 600 ohms). We place one end of the resistor on the same line as the LED.

Now we connect the resistor’s other end to the railing for the Ground.

Install Arduino On Mac Keyboard

We use a wire to connect it to the Ground pin on the Arduino.

The closeup of the Arduino after the connections have been made will look like this.

We then connect the other end of the LED to the pin number 12 which we are programming for.

The closeup of the breadboard after the connections have been made will look like this.

Since the program is already on the Arduino, we should immediately be able to see the light blink.

Install Arduino On Mac Computers

Here's a video explaining in entirety how to program an Arduino using a Mac:

Install Arduino On Mac Download

*Contributors: Written by Vidya Prabhu; Lead image by: Leonel Cruz
